HANDSET Alpha Panel Formwork

The robust and economical formwork system for crane-independent applications –
Less weight, more flexibility, better handling



HANDSET Alpha is a light-weight steel frame / plywood faced formwork system for walls, foundations and columns. The system consists of a low number of sophisticated components and multifunctional panels that make handling intuitive.

This streamlined, integrated portfolio keeps the need for on-site training to a minimum and saves valuable time and costs. Only two people are needed to assemble the system. A crane is not required. The high quality steel and powder-coated panels make HANDSET Alpha particularly durable and reduce maintenance costs.

HANDSET Alpha Panel Formwork
HANDSET Alpha is a robust entry-level formwork system for walls, foundations and columns. The system consists of a low number of sophisticated components and multifunctional panels that make handling intuitive.
HANDSET Alpha Panel Formwork

Easy assembly

Assembly is carried out quickly and intuitively by just two people – without the need for a crane. This makes HANDSET Alpha particularly efficient.

Efficient material management

The multi-panels with integrated tie holes at 5 cm intervals provide a high degree of flexibility and reduce the volume of material held on site.

HANDSET Alpha Panel Formwork

Time and cost savings

The low number of reusable system components reduces the amount of material loss on the construction site as well as the amount of timber required.

Fast concreting with 2-in-1 system

HANDSET Alpha is – with the small portfolio consisting of only a few elements and multi-panels – the right choice for the erection of walls and columns. The high permissible concrete pressure of 60 kN/m² for walls and up to 75 kN/m² for columns minimizes errors and speeds up the concreting process. Columns range from 150 mm x 150 mm up to 900 mm x 900 mm without tie rods.

HANDSET Alpha Panel Formwork
HANDSET Alpha is – with the small portfolio consisting of only a few elements and multi-panels – the right choice for the erection of walls and columns. The high permissible concrete pressure of 60 kN/m² for walls and up to 75 kN/m² for columns minimises errors and speeds up the concreting process.

Enjoy our PERI Services.
With PERI HANDSET Alpha you are never on your own.

PERI is your professional formwork partner. We support you in formwork design with our professional engineering, as well as on the job site with training and supervision. Get in touch to know more about our complete service package, which makes us the preferred formwork and scaffolding provider for many customers all over the world.

Contact our PERI Service

Successful jobsites with HANDSET Alpha Panel Formwork

Our customers are convinced of the advantages of HANDSET Alpha Panel Formwork.

Find out more about the system and customers' opinions.

Watch the video:

Hotel construction, Sicily, Italy

Read local project reports from  South Africa

De Zalze Golf Estate-Housing project

A housing project in the Western Cape, South Africa.

Stellenbosch , South Africa

Technical details of HANDSET Alpha

  • Robust panels with a weight of 34.5 kg/m²
  • A small portfolio with of only a few elements differing in terms of height (3.00 m/1.50 m/1.20 m) and width (0.90 m 0.60 m/0.30 m)
  • All of the panels can be used as multi-panels
  • Max. permissible fresh concrete pressure: 60 kN/m² (for walls)
  • Max. permissible fresh concrete pressure: 60 kN/m² (for columns up to 900 mm x 900 mm)
  • Max. permissible fresh concrete pressure: 75 kN/m² (for columns up to 600 mm x 600 mm)
  • Columns ranging from 150 mm x 150 mm up to 900 mm x 900 mm without tie rods
  • Easy cleaning due to inclined profiles in combination with high-quality powder-coated frames

Watch the video to learn more about the technical details of HANDSET Alpha Panel Formwork:

More information needed?

Sales contact

Your sales representative will be happy to assist you with your questions.

Send us a message

Product flyer

Please download the HANDSET Alpha Flyer for more information:

Download brochure

Product page

Click here to go to the product page for more details:



HANDSET Alpha offers a high degree of application flexibility. The panels can be used for a wide range of construction projects.

HANDSET Alpha Panel Formwork
